LPAR2RRD installed in IBM i

Inocencio

Hi

Have installed LPAR2RRD in my IBMi (V7R4)

Have did these cmds without problem:

CHGJOBD JOBD(LPAR2RRD/LPAR2RRD) JOBQ(LPAR2RRD/LPAR2RRD) TEXT('RTV_SYSSTS') USER(LPAR2RRD) RQSDTA(*NONE) INLLIBL(LPAR2RRD QGPL QTEMP)
CHGUSRPRF USRPRF(LPAR2RRD) JOBD(LPAR2RRD/LPAR2RRD)
MKDIR DIR('/home/LPAR2RRD')
GRTOBJAUT OBJ(QSYS/QPMLPMGT) OBJTYPE(*SRVPGM) USER(LPAR2RRD) AUT(*use)
PING RMTSYS('LPAR2RRD-SERVER.SERVER.COM') -- where LPAR2RRD was installed
CHGCMDDFT CMD(LPAR2RRD/RTV_SYSSTS) NEWDFT('IPADR(LPAR2RRD-SERVER.SERVER.COM)')
CHGUSRPRF USRPRF(LPAR2RRD) PASSWORD(*NONE)
ADDLIBLE LPAR2RRD
GO MENU
  Select: 14 Accept Software Licensing Agreement ➞ page down ➞ F14 Accept
  OK:CL_ACCEPT Expiration date of this client is 2017-06-25

The question: How start de dashboard? I'd tried lpar2rrd:8162 without response.
Thanks
Inocencio

Inocencio

QPJOBLOG_LPAR2RRD_SND_SYSSTS_648360_1.txt

Uploaded Apr 7, 202528.06 KB

Pavel

job log says: error: 3425, it means: A remote host refused an attempted connect operation.

1.

can you ping to lpar2rrd server?

can you telnet to lpar2rrd server port 8162

both as per our docu: https://lpar2rrd.com/as400.php#as400-install

2.

on lpar2rrd server:

is there lpar2rrd daemon running on port 8162:

netstat -na | grep 8162
